Garrett GTX4718R (900-1600 HP)

Available to order
No reviews
€4.043,95 inc. VAT
Turbine Housing Option (A/R, Inlet, Outlet)
Price Match
Product details
  • SKU GAR-804878-5007S

Share this product on your social networks :

Description
Horsepower:
900 - 1600
Displacement:
2.5L - 10.0L
Super Core Reference Data Compressor Turbine
Super Core PN CHRA PN Inducer Exducer Trim A/R Inducer Exducer Trim
804878-5007S 769210-0023 88mm 118mm 56 .69 93mm 84mm 82
Features:
  • Features original gtx comp wheel aerodynamics.
  • New fully-machined speed sensor port.
  • Super core and turbine kit sold separately.
  • V-band compressor outlet configuration.
  • Lightweight billet backplate.

Garrett® GTX Series turbochargers are designed specifically for the hard-core enthusiast who wants optimal performance. The forged fully-machined billet aluminum compressor wheels feature next generation aerodynamics that provide a larger horsepower range and maximize boost response.

Ported shroud compressor housings increase surge resistance and provide reliable, continuous power throughout the power band. A dual ceramic ball bearing cartridge prolongs the lifespan and improves shaft balance. The water cooled CHRA keeps housing temperatures to a minimum. The turbine wheel is constructed from Inconel, a Super Alloy that maintains strength during prolonged exposure to high exhaust gas temperatures.

Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. GTX Series turbochargers are used by today’s top motorsports teams and are ready to boost you to the podium or wherever your destination may be.
